Auto wires are also called low -voltage wires, which are different from ordinary home wires. Ordinary home wires are copper single stamens, with a certain hardness. The automotive wires are copper -multi -streaming soft wires, and some soft wires are as thin as hair. Several or even dozens of soft copper wires are wrapped in plastic insulating tube (polyvinyl chloride). It is soft but not easy to break.
The common specifications of the wires in the car wires are nominal cross -sectional area of 0.5, 0.75, 1.0, 1.5, 2.0, 2.5, 4.0, 6.0 and other square millimeters. , 2.5, 4.0, 6.0, etc.), each has the allowable load current value to be equipped with wires with different power equipment. Taking the entire vehicle beam as an example, the 0.5 specification line is suitable for instrument lights, indicators, door lights, top lights, etc.; 0.75 specification lines are suitable for license plate lights, small lights, brake lights, etc Lights, etc.; 1.5 specification lines are suitable for headlights, speakers, etc.; Main electricity sources such as generating electrical and electrical hub lines and iron wires require 2.5 to 4 square millimeter wires. This only refers to the general car, the key depends on the maximum current value of the load. For example, the iron wire and the positive power line of the battery are used alone. Above, these “giant” wires will not be incorporated into the main line.
